Nominal pressure(PN):16~40
Working pressure difference (Mpa): 0.01~0.8, etc
Displacement (m3/h): 8~20
Connection: flange, thread
Nominal size (DN): 25~80 etc
Operating temperature: normal temperature
1. Fully automatic continuous operation, discharge when there is water, automatic shutdown when there is no water, and the discharge rate of sedimentary water (liquid) is 100%.
2. Double guidance, high action reliability, no gas leakage during operation.
3. The internal parts are all made of stainless steel, which has a long service life.
4. Good cleaning performance, wear resistance and corrosion resistance.
5. Easy installation, stable operation and convenient sewage discharge.
Application: It is suitable for the working condition that can automatically separate the gas-liquid two-phase medium with a specific gravity difference greater than 0.3, and is conducive to the recycling of the liquid-phase medium.
